ASUS PRIME H810M-E-CSM Intel H810 LGA 1851 (Socket V1) micro ATX
View 1
View 2
View 3
View 4
View 5
View 6

ASUS PRIME H810M-E-CSM Intel H810 LGA 1851 (Socket V1) micro ATX

£81.06

£97.27 inc. VAT

Low Stock(37)MPN: 90MB1N20-M0EAYC
🚚 Next-day delivery £4.95
Quantity:1
1
2
3
4
5
6
7
8
9
10+

Key Features

ASUS PRIME H810M-E-CSM
Motherboard
micro ATX
LGA1851 Socket
H810 Chipset
USB-C 3.2 Gen 1, USB 3.2 Gen 1
Gigabit LAN
onboard graphics (CPU required)

Product Overview

AI-generated summary

At ~£84.80 ex-VAT, the ASUS PRIME H810M-E-CSM is the kind of board that makes sense when you’re building a straightforward office/desk machine and you don’t want to overpay for features you’ll never use. ASUS’ PRIME line tends to be solid on day-to-day reliability and BIOS usability, and the micro-ATX format is a nice fit for cost-controlled builds where space is tight but you still want a “proper” branded motherboard rather than a no-name gamble. If your plan is a basic workstation with standard expansion needs, it’s a reasonable value choice.

That said, I wouldn’t buy it if your business depends on heavy expansion, lots of fast peripherals, or you expect to do anything remotely “plug-and-tweak” heavy over its life. Lower-end chipsets and mainstream boards like this usually trade away future flexibility, so if you’re likely to add multiple high-bandwidth cards/disks or want more headroom for upgrades, you’ll be happier spending a bit more on a more feature-complete model. Bottom line: good for simple, predictable builds; not ideal if you’re trying to build a long-term upgrade platform.

Specifications

Processor

Processor manufacturerIntel
Processor socketLGA 1851 (Socket V1)
Compatible processor seriesIntel Core Ultra (Series 2)
Supported processor socketsLGA 1851

Memory

Supported memory typesDDR5-SDRAM
Number of memory slots2
Memory slots typeDIMM
Memory channelsDual-channel
ECC сompatibilitynon-ECC

Storage controllers

Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2,SATA III
Number of HDDs supported4
Number of storage drives supported6

Graphics

Parallel processing technology supportNot supported

Internal I/O

USB 2.0 connectors1
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
Number of SATA III connectors4
S/PDIF out connectorY
Front panel audio connectorY

Rear panel I/O ports

USB 2.0 ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
DisplayPorts quantity2

Network

Ethernet LANY
Ethernet interface typeGigabit Ethernet
Wi-FiN

Features

Motherboard chipsetIntel H810
Audio output channels7.1 channels
Component forPC
Motherboard form factorMicro ATX
Motherboard chipset familyIntel
